Analog/mixed-signal IP for
electro-photonic systems.

StarIC's library forms the analog foundation of electro-photonic platforms, enabling faster integration and lower risk. Start with photonic-electronic interface and high-speed interconnect, or browse the full catalog below.
Photonic interface IP Electro-photonic interconnectDiscuss licensing
Photonic interfaceHigh-speed interconnectData conversionIntelligent edgeAnalog foundation
Optical interconnect

Photonic-Electronic Interface

Analog/mixed-signal/photonics blocks that bridge photonics and CMOS on GF Fotonix™. The interface layer for electro-photonic interconnect in AI, HPC, and hyperscale data centers.
TIA · 100G NRZSilicon validated
High-Speed Transimpedance Amplifier

Up to 100 Gbps NRZ on GF Fotonix™, silicon-proven, GDS ready.

View IP
MRM · 100GSilicon validated
Micro-Ring Modulator Driver

Up to 100 Gbps NRZ/PAM4 on GF Fotonix™, silicon-proven, GDS ready.

View IP
TIA · 32G NRZIn development
32 Gbps NRZ Transimpedance Amplifier

32 Gbps NRZ TIA for GF Fotonix™, under development.

View IP
TIA · 64G PAM4In development
64 Gbps PAM4 Transimpedance Amplifier

64 Gbps PAM4 TIA for GF Fotonix™, under development.

View IP
MRM · 32G NRZIn development
32 Gbps NRZ Micro-Ring Modulator Driver

32 Gbps NRZ MRM driver for GF Fotonix™, under development.

View IP
Control Loop PHYIn development
MRM Control Loop PHY

Low-noise, low-power optical control loop with high-resolution ADCs, DACs, and digital control.

View IP
Multi-gigabit links

High-Speed Interconnect

SerDes and equalization IP for chiplet, AI, HPC, and data-center connectivity, architected for power, performance, and reach.
Platform IPIn development
Die-to-Die / Short-Reach SerDes

32 Gbps UCIe-class links with CTLE and CTLE+DFE on GF Fotonix™, under development.

View IP
Platform IPSilicon validated
Long-Reach SerDes

32 Gbps PCIe-class links, 4-tap Tx FIR, CTLE, 12-tap DFE, 30 dB IL target.

View IP
APX PHYSilicon validated
APX PHY for Physical AI

16 Gbps APXpress PHY with 4-tap Tx FIR, CTLE, 12-tap DFE, and 30 dB IL target. Part of the Inova APXpress ecosystem.

View IP
Signal chain depth

Precision Data Conversion

Ultra-low-power precision ADCs and flexible conversion architectures for intelligent and electro-photonic systems.
STAR1010Silicon validated
Ultra-Low-Power 16b Audio ADC

96 dBA dynamic range, <200 µA, highly configurable, GDS ready in 40nm.

View IP
STAR1011Silicon validated
Ultra-Low-Power 16b Audio ADC

92 dBA dynamic range, <110 µA, GDS ready in 65nm.

View IP
STAR3000Silicon validated
16b 10 Hz Sensor ADC

>96 dB over 10 Hz bandwidth, <30 µA, samples negative voltages to −0.25 V.

View IP
STAR3001Silicon validated
14b 50 Hz Sensor ADC

>80 dB SNR over 50 Hz bandwidth.

View IP
STAR3002Silicon validated
12b 560 kS/s ADC

>10b ENOB, <0.3 mA, cyclic architecture.

View IP
STAR3003Silicon validated
11b 1.5 MS/s ADC

10b ENOB, <200 µA, SAR topology.

View IP
Sensing & edge AI

Intelligent Edge Interfaces

Integrated sensor, audio, and IoT interface IP with performance-optimized analog front-ends for intelligent edge systems alongside our interconnect platforms.
STAR1000Silicon validated
Ultra-Low-Power Microphone / Audio / IoT Interface

Complete AFE with integrated high-performance ADC, GDS ready, silicon proven.

View IP
STAR1020
Ultra-Low-Power Hybrid Noise-Cancelling DSP

RTL-ready engine, <2 µs latency, patented technique, demo platform available.

View IP
STAR2000Silicon validated
Capacitive Touch Controller (Large Screens)

Projective capacitive touch (PCTS), highly scalable for panel sizes.

View IP
STAR2001Silicon validated
Capacitive Touch Controller (Mobile Screens)

Smartphone and tablet PCTS controller ASIC IP.

View IP
STAR2010Silicon validated
PZT 3-Axis MEMS Gyro Interface

ASIC interface for 3-axis PZT MEMS gyroscope.

View IP
STAR2011Silicon validated
Battery Monitoring Gas Gauge

Ultra-low power BMU for voltage and charge monitoring.

View IP
STAR2020Silicon validated
Digital Temperature Sensor

Delta-sigma architecture, ±2 °C accuracy, flexible resolution.

View IP
STAR2021Silicon validated
Low-Voltage Digital Temperature Sensor

SAR architecture with built-in low-jitter ring oscillator.

View IP
STAR2030Silicon validated
Digital FM IR Receiver + Speaker Driver

4 stereo audio channels, 2.3–5.7 MHz, stereo PDM H-bridge drivers.

View IP
STAR2040Silicon validated
Cascoded GaN High-Voltage Driver

20 A capable CMOS cascode driver for GaN/SiC power FETs, <15 mΩ on-resistance.

View IP
Platform building blocks

Analog & Power Foundation

Reference, power, clocking, and peripheral IP that completes production-ready electro-photonic and mixed-signal platforms, proven across multiple foundry nodes.
STAR4000Silicon validated
1.8 to 5.6 V Charge Pump

Frequency-regulated voltage doubler and tripler with programmable output.

View IP
STAR4001Silicon validated
Buck Converter

1–1.8 V output, 3–5.5 V input, >90% efficiency, 500 mA max load.

View IP
STAR4002Silicon validated
Boost Converter

8–15 V output, 3–5.5 V input, digital controller, up to 90% efficiency.

View IP
STAR4003Silicon validated
Voltage Doubler Charge Pump

1.8–3.6 V output, 0.9–1.8 V input, >90% efficiency, 20 mA max.

View IP
STAR5010Silicon validated
Low-Power 1.2 V Bandgap

<5 µA, <0.5% temperature accuracy from −20 °C to 80 °C.

View IP
STAR5011Silicon validated
High-Voltage LDO

Up to 14 V input, configurable output to 12 V, 15 mA output.

View IP
STAR5012Silicon validated
Low-Voltage LDO

Up to 3.3 V input, output to 1.8 V, 5 mA, no external components.

View IP
STAR5013Silicon validated
32 MHz Low-Power Oscillator

±2% frequency stability from −10 °C to 55 °C, low jitter.

View IP
STAR5000
Digital I2C Controller

Synthesizable controller for multi-device configuration and low-speed data transfer.

View IP
STAR5001
Digital SPI Controller

Synthesizable controller, up to 40 MHz external bus speeds.

View IP
Licensing

License IP for your platform.

StarIC's catalog spans photonic interface, high-speed interconnect, data conversion, and analog foundation blocks, many silicon-proven on advanced CMOS and silicon photonics nodes. We scope integration support and deliverables to each IP block and your design flow.

Discuss licensing Electro-photonic interconnectCustom silicon programs

Need something not in the catalog? StarIC architects multi-domain analog/mixed-signal designs from scratch when off-the-shelf blocks don't fit. Explore custom silicon →
